Lumiprobe 抗體標記試劑盒說明書Antibody labeling kits

The kit is used for the preparation of labeled antibodies having 2.5-3 labels per antibody. The kit contains all reagents and materials for ten labeling reactions, each for 100 ug of the antibody. The dye is an NHS ester, taken in controlled excess. It reacts with the amine groups of lysines the antibody at mild alkaline pH. The purification of the antibody is achieved by gel filtration using spin columns. These kits contain sulfonated, water soluble dyes, that are most suitable for the labeling of sensitive proteins, including antibodies.

Kit components

Protocol

1. Antibody preparation.

Optimal conditions for the labeling reaction are the following: antibody at a concentration of 1 mg/mL dissolved in 0.1 M sodium hydrocarbonate solution. Sodium azide is compatible with the labeling. If concentration of antibody is below 1 mg/mL, it should be concentrated. Antibody preparation should be free of aminoacids, proteins like BSA and buffer components that bring pH to unfavourable (2-7.5 or 9-12) ranges.

2. Setting up the reaction.

2.1. Add a solution of antibody in sodium hydrocarbonate (100 ug in 100 uL*) to the fluorophore, vortex, and incubate for 30 min at room temperature.

* if a smaller amount of antibody is to be labeled, dissolve lyophilized dye in 10 uL of anhydrous DMSO, and take 1 uL of the solution per 10 ug of antibody. The solution of dye in DMSO should be consumed immediately.

3. Purification of the labeled antibody.

3.1. Prepare the column. The column should be at room temperature prior to use. The gel should be resuspended using vortex. Put the column into a waste receptacle (without cap), and centrifuge for 2 min at 1,000 g (speed must be carefully controlled – for standard 6 cm rotor, 1,000 g = 3800 rpm). The small bulge of the column should be oriented outwards.

3.2. Apply 400 uL of 1x PBS buffer, centrifuge for 2 min at 1,000 g.

3.3. Remove the column from waste receptacle. Put it into collection tube (with cap). Apply 100 uL of the reaction mixture onto the column, incubate for 1 min, and elute the antibody by centrifugation for 2 min at 1,000 g. Add 1/100 volume of 100x sodium azide. Antibodies can be aliquoted to improve their shelf life. Current aliquot can be stored at +4°С the rest at -20°С.

4. Measurement of dye to antibody ratio.

To calculate dye to antibody ratio, measure absorption spectrum of the conjugate, or absorption at 280 nm (A_AB), and at dye absorption maximum (A_Dye). A typical absorption spectrum of a dye labeled antibody is shown below. Depending on the dye, wavelength of the maximum may vary.

An absorption spectrum of a labeled antibody contains dye peak (with longer wavelength), and antibody peak (at around 280 nm). Dye to antibody ratio is calculated using the following formula:

with?Dye/AB?– average number of fluorophores per antibody molecule,?A_dye?– optical density of the sample at dye absorption maximum,?A_AB?– sample optical density at 280 nm,?ε_AB?– molar extinction coefficient of antibody at 280 nm (210,000 for IgG),?ε_Dye?– molar extinction coefficient of dye at absorption maximum (see table below),?CF₂₈₀?– correction factor for dye (see table below).

Example of calculation

After labeling of IgG antibody with sulfo-Cyanine5 and purification, a solution has been obtained with absorption spectrum above. Determine dye to protein ratio.

Using absorption spectrum, the following values can be found:?A_Dye?= 0.184 at dye absorption maximum (646 nm, see the table),?A_AB?= 0.066 (at 280 nm),?ε_AB?= 210000 for IgG;?ε_Dye?= 271,000, and?CF₂₈₀?= 0.04.

Dye/AB?– is 2.43 fluorophore molecules per antibody.

Interpretation of results, and antibody storage

In most cases, optimal dye to antibody ratio is 2-3 dye molecules per antibody. Increase of dye loading above this value does not improve fluorescent signal because of the concentrational quenching of the fluorescence. When too few fluorophores are attached during the reaction, decrease antibody loading per reaction. Use of expired kit can also lead to this result.

We recommend to test binding of labeled antibodies with their antigens. The labeled antibodies can be stored at -20°С. An aliquot that is currently in use, should be stored at +4°С to avoid freeze-thaw cycles. The stability of the conjugate is determined by antibody itself rather than fluorophore or the chemical bond. Labeled antibodies should not be exposed to direct sunlight for extended time, but tolerate ambient lighting well.

Lumiprobe 蛋白質標記試劑盒 Protein labeling kits

上海金畔生物代理Lumiprobe品牌產品，歡迎新老客戶訪問Lumiprobe官網或者咨詢我們獲取更多相關產品信息。

Lumiprobe protein labeling kits contain pre-aliquoted reactive dye, all necessary auxiliary components and buffers, and desalting spin columns to achieve efficient, reproducible labeling of antibodies, and other proteins.

The labeled protein is purified by means of gel filtration on gel filled spin columns that are enclosed. This protocol ensures complete removal of the unbound dye, and excellent recovery of the labeled product. The protein is eluted in PBS buffer, ready for the use in most downstream applications.

The protocol is quick, effortless, and easy to follow.

Lumiprobe 探針蛋白標記試劑盒包含預先引用的活性染料、所有必需的輔助成分和緩沖器，以及脫鹽自旋柱，以實現抗體和其他蛋白質的高效、可復制的標記。

標記蛋白是通過凝膠過濾純化的凝膠填充自旋柱是封閉的。該協議確保完全去除未結合染料，并出色地恢復標記產品。該蛋白在PBS緩沖液中被洗脫，可以在大多數下游應用中使用。

該試劑盒具有快速，毫不費力，易于遵循等優點。
